Provides protection against earth fault/leakage current and unction of isolation
High short-circuit current withstand capacity
Applicable to terminal and pin/U type busbar connection On off display function of contact position
Fire resistant plastic parts endures abnormal heating and strong impact
Automatically disconnect the circuit when earth fault/leakage current occurs and exceeds the rated sensitivity
| Type | Standard | IEC61008 | |
|
Electrical features |
Rated current ln | A | 25, 32, 40, 63 |
| Poles | P | 2, 4 | |
| Rated voltage Ue | V | 2P: 230V~ 50/60Hz 4P: 400V~ 50/60Hz | |
| Rated conditional short-circuit current Icn | A | 6000 | |
| Rated residual operating current I △n | mA | 30,100,300 | |
| Rated residual non operating current I △no | 0.5I△n~I△n | ||
| Action time | s | instantaneous type ≤0.1s | |
| Mechanical
features |
Protection degree | IP20 | |
| Ambient temperature
(with daily average≤35℃) |
℃ | -5~+40 | |
| Installation | Mounting | DIN rail 35mm, panel mounting |
